Atlas Platinum PVL-14 — 14,000 lb 4-Post Lift in Victoria BC | SVI Automotive Equipment
Four-Post · Commercial Grade · ALI Certified

Atlas Platinum PVL-14

An ALI-certified 14,000 lb commercial-grade four-post lift for trucks, vans, SUVs and light-to-medium commercial vehicles.

OverviewFeaturesSpecsWarranty
Atlas Platinum PVL-14 four-post lift raising a box truck

The Atlas Platinum PVL-14 is a heavy-duty, commercial-grade four-post lift designed with the professional shop in mind. With 14,000 lbs of ALI-certified capacity and extra-tall, extra-wide, extra-long runways, it handles cars, vans, SUVs, trucks and even some light and medium-duty commercial vehicles.

14,000 lbsALI CertifiedAtlas WarrantyIn Stock · Vancouver Island

$0-down lease-to-own financing available — see options. Authorized Atlas dealer with professional installation across Vancouver Island.

Atlas Automotive Equipment
Authorized Atlas Automotive Equipment Dealer
Every Atlas lift is ALI-certified where applicable, covered by manufacturer warranty, and backed by SVI's local installation and service.

About the Atlas Platinum PVL-14

The Atlas PVL-14 lifts with a high-strength cable system and an oversized hydraulic cylinder tucked under the runway, powered by a 220V single-phase ALLY Hydraulic AL2650 power unit. An adjustable lock ladder and double-lock safety system hold the load, and the air-operated single-point lock release (external air supply required) makes lowering simple.

Tracks between the runways let you add a rolling bridge jack (Atlas recommends the Platinum RJ7000, sold separately) for wheels-free brake and suspension work. Steel approach ramps and mounting hardware are included. With 69 1/2" of clearance under the runways and a 184" maximum wheelbase, there's room for long trucks and working space underneath.

Built-In Advantages

ALI-certified 14,000 lb commercial-grade four-post lift
Extra tall, extra wide and extra long runways
Cable system with oversized under-runway hydraulic cylinder
Adjustable lock ladder with double-lock safety system
Air-operated single-point lock release (external air required)
Tracks for a rolling bridge jack (sold separately)
ALLY Hydraulic AL2650 power unit, MET Labs certified
Steel approach ramps and mounting hardware included

Full Specs

Lifting Capacity14,000 lbs
TypeFour-post, commercial grade
Lifting Height76 1/2" (6' 4 1/2")
Clearance Under Runways69 1/2" (5' 9 1/2")
Overall Height92 1/2" (7' 8 1/2")
Overall Length211 1/2" (251 1/2" with ramps)
Overall Width131 3/4" (140 1/2" with motor)
Runway Length / Width205 1/2" / 20"
Width Between Runways43"
Maximum Wheelbase184"
Drive-Thru94 1/2"
Lock ReleaseAir-operated single point (external air required)
Power UnitALLY Hydraulic AL2650 (MET Labs certified)
Power220V single phase, 30A breaker
CertificationALI Certified
Warranty5 yr structural / 2 yr cylinders / 1 yr power unit

Coverage

Warranty Information

Every Atlas lift supplied and installed by SVI Automotive Equipment is covered by the Atlas manufacturer warranty and backed by our local service across Vancouver Island.

Standard Manufacturer Warranty

  • 5 years on structural components
  • 2 years on hydraulic cylinders
  • 1 year on electric / air-hydraulic power units
  • 90 days on wear items

Optional Extended Warranty

Atlas offers two extended-warranty programs you can add at purchase, covering parts including hydraulic hoses, fittings, pumps, and cylinders:

  • BLUE 2+ — 2-year extended coverage
  • PLATINUM 3+ — 3-year extended coverage

Ask us which program fits your shop. Warranty terms are set by Atlas Automotive Equipment and subject to their terms and conditions (the limited warranty covers parts, not labour); SVI Automotive Equipment handles local warranty service and support.
