An 8,000 lb four-post storage and service lift built for homeowners and restoration shops.

The Atlas Garage Pro 8000 is an 8,000 lb four-post storage and service lift, designed and built for homeowners and restoration shops. Drive straight on, raise the vehicle on its own wheels, and park a second car underneath, or bring a project up to a comfortable working height. It runs on 110V power with a 30A breaker.
$0-down lease-to-own financing available — see options. Authorized Atlas dealer with professional installation across Vancouver Island.
It uses the same lock ladder column system found on professional lifts, with a double-lock safety system and a manual single-point release that frees all four locks at once. Flow restrictor valves and zerk fittings at each corner keep it running smoothly.
It doesn't need to be anchored to the floor, and the included polyurethane caster kit lets you roll it across an epoxy floor without marking it. Steel approach ramps, three drip trays, steel jack trays and rubber wheel chocks are all included. Anchor bolts are optional if you plan to use it many times a day.
| Lifting Capacity | 8,000 lbs |
| Type | Four-post storage / service (homeowner) |
| Lifting Height | 72" to top of runway |
| Clearance Under Runways | 67 1/2" |
| Lock Positions | Every 6" from 24" to 72" |
| Column Height | 83" |
| Overall Width | 104 3/8" (114" with motor) |
| Overall Length | 175 1/2" (207 1/2" with ramps) |
| Runway Length / Width | 165 1/2" / 21 1/4" |
| Maximum Wheelbase | 153 1/2" |
| Drive-Thru | 80 1/2" |
| Power | 110V single phase, 30A breaker |
| Anchoring | Not required (anchor bolts optional) |
| Warranty | 2 yr structural / 1 yr hydraulic & power unit |
Every Atlas lift supplied and installed by SVI Automotive Equipment is covered by the Atlas manufacturer warranty and backed by our local service across Vancouver Island.
Atlas offers two extended-warranty programs you can add at purchase, covering parts including hydraulic hoses, fittings, pumps, and cylinders:
Ask us which program fits your shop. Warranty terms are set by Atlas Automotive Equipment and subject to their terms and conditions (the limited warranty covers parts, not labour); SVI Automotive Equipment handles local warranty service and support.
