Atlas Garage Pro 8000 — 4-Post Storage Lift in Victoria BC | SVI Automotive Equipment
Four-Post Storage / Service

Atlas Garage Pro 8000

An 8,000 lb four-post storage and service lift built for homeowners and restoration shops.

OverviewFeaturesSpecsWarranty
Atlas Garage Pro 8000 vehicle lift

The Atlas Garage Pro 8000 is an 8,000 lb four-post storage and service lift, designed and built for homeowners and restoration shops. Drive straight on, raise the vehicle on its own wheels, and park a second car underneath, or bring a project up to a comfortable working height. It runs on 110V power with a 30A breaker.

8,000 lbsAtlas WarrantyIn Stock · Vancouver Island

$0-down lease-to-own financing available — see options. Authorized Atlas dealer with professional installation across Vancouver Island.

Atlas Automotive Equipment
Authorized Atlas Automotive Equipment Dealer
Every Atlas lift is ALI-certified where applicable, covered by manufacturer warranty, and backed by SVI's local installation and service.

About the Atlas Garage Pro 8000

It uses the same lock ladder column system found on professional lifts, with a double-lock safety system and a manual single-point release that frees all four locks at once. Flow restrictor valves and zerk fittings at each corner keep it running smoothly.

It doesn't need to be anchored to the floor, and the included polyurethane caster kit lets you roll it across an epoxy floor without marking it. Steel approach ramps, three drip trays, steel jack trays and rubber wheel chocks are all included. Anchor bolts are optional if you plan to use it many times a day.

Built-In Advantages

8,000 lb four-post storage / service lift
Lock ladder column design with double-lock safety system
Manual single-point lock release
Runs on 110V power (30A breaker)
Does not need to be anchored; polyurethane caster kit included
Steel ramps, 3 drip trays, jack trays and wheel chocks included
Built for homeowners and restoration shops
Professional installation available

Full Specs

Lifting Capacity8,000 lbs
TypeFour-post storage / service (homeowner)
Lifting Height72" to top of runway
Clearance Under Runways67 1/2"
Lock PositionsEvery 6" from 24" to 72"
Column Height83"
Overall Width104 3/8" (114" with motor)
Overall Length175 1/2" (207 1/2" with ramps)
Runway Length / Width165 1/2" / 21 1/4"
Maximum Wheelbase153 1/2"
Drive-Thru80 1/2"
Power110V single phase, 30A breaker
AnchoringNot required (anchor bolts optional)
Warranty2 yr structural / 1 yr hydraulic & power unit

Coverage

Warranty Information

Every Atlas lift supplied and installed by SVI Automotive Equipment is covered by the Atlas manufacturer warranty and backed by our local service across Vancouver Island.

Standard Manufacturer Warranty

  • 2 years on structural components
  • 1 year on power units, cylinders and major components
  • 90 days on wear items

Optional Extended Warranty

Atlas offers two extended-warranty programs you can add at purchase, covering parts including hydraulic hoses, fittings, pumps, and cylinders:

  • BLUE 2+ — 2-year extended coverage
  • PLATINUM 3+ — 3-year extended coverage

Ask us which program fits your shop. Warranty terms are set by Atlas Automotive Equipment and subject to their terms and conditions (the limited warranty covers parts, not labour); SVI Automotive Equipment handles local warranty service and support.
